GAOHUI 15V 1500A Industrial IGBT Anodizing Rectifier – High Efficiency DC Power Supply for Aluminum Surface Treatment

Part 1: Key Features & Engineering Highlights
– Advanced Germany technology cooling system ensures stable operation under continuous heavy-duty loads, making it a top choice for any industrial high frequency rectifier factory.
– Fully sealed IGBT modules deliver exceptional energy conversion efficiency, reducing your heavy-duty DC power supply price per ampere over the machine’s lifetime.
– Digital multi-stage programmable profile control allows precise voltage and current ramping for architectural profile finishing and sulfuric acid anodizing processes.
– Integrated RS485 Modbus RTU and Ethernet interfaces enable seamless integration into existing factory automation systems, a critical feature for any IGBT rectifier manufacturer.
– Custom current voltage rectifier configuration available from 1V to 1000V and 1A to 100,000A, ensuring a perfect match for your specific anodizing line requirements.

Part 2: Technical Specifications Table

Part 3: Advanced Built-in Protection Systems
Our 15V 1500A rectifier is engineered with multi-layer safety features including overvoltage protection, overcurrent protection, short circuit protection, overtemperature shutdown, and phase loss detection. Each unit undergoes a rigorous 48-hour burn-in test under simulated anodizing load conditions to ensure zero failure in harsh industrial environments. The soft-start ramp-up function prevents current surges that can damage delicate aluminum workpieces during initial power application.

Part 4: Target Industrial Applications
This power supply is specifically designed for aluminum anodizing lines, architectural profile finishing, and sulfuric acid anodizing processes. It also excels in hard anodizing of aluminum alloys, decorative anodizing for consumer electronics, and functional coating for aerospace components. Additional applications include electrowinning of non-ferrous metals, precious metal plating, and electroforming operations where precise DC current control is mandatory.

Part 5: Customization and Tailored Engineering Services
As a leading IGBT rectifier manufacturer, GAOHUI offers complete customization from 1V to 1000V and 1A to 100,000A, with AC input and DC output only. Optional functional modules include Digital Process Timer for batch control, Multi-Stage Programmable Profile Control for complex anodizing cycles, Ampere-Minute Integrator for precise coating thickness, Automatic Reverse Polarity for desmutting steps, and Soft-Start Ramp-Up for gentle current application. Local/Remote Control options are available via Push-Button panel or HMI Touch Screen. Communication interfaces include RS485 Modbus RTU, Ethernet, and 4-20mA analog signals. The pulse function supports 1-100% duty cycle and 1-3000Hz frequency adjustable, enabling advanced pulse anodizing techniques for superior surface quality.
