GAOHUI 12V 1500A 18KW IGBT Electroplating Rectifier with Microsecond Fault Response for Industrial Nickel, Chrome, and Zinc Plating

Key Features
– Precision Output: Provides adjustable DC voltage from 0 to 12V and current from 0 to 1500A, ensuring stable and repeatable electroplating results for high-volume production.
– High Efficiency: IGBT inverter technology delivers ≥90% energy conversion efficiency, reducing operational costs and heat generation compared to traditional SCR rectifiers.
– Digital Control: Integrated digital display for real-time monitoring of voltage and current, with local or remote control via push-button or HMI touch screen interface.
– Robust Construction: Designed for 24/7 industrial operation with forced air cooling and a durable cabinet, suitable for harsh plating environments.
– Variable Frequency Conversion: Advanced inverter stage converts high-voltage DC into precise, low-ripple output for uniform coating thickness on parts up to 3 sq ft.

Technical Specifications

Built-in Protection Systems
– Overvoltage Protection: Automatically shuts down output if voltage exceeds safe limits, preventing damage to plated parts.
– Overcurrent Protection: Limits current to 1500A maximum, with automatic shutdown on short circuit or overload.
– Overtemperature Protection: Thermal sensors trigger cooling fans and shutdown if internal temperature exceeds threshold.
– Microsecond-Level Fault Response: IGBT driver circuitry detects and isolates faults in less than 1 microsecond, safeguarding both rectifier and plating bath.
– Reverse Polarity Protection: Prevents connection errors that could damage sensitive plating processes.

Main Applications
– Electroplating: Ideal for nickel, chrome, zinc, copper, gold, silver, and hard chrome plating on steel parts up to 3 sq ft surface area.
– Electroforming: Produces uniform metal deposits for molds and precision components.
– Anodizing: Suitable for aluminum anodizing processes requiring low-voltage, high-current DC.
– Electrolysis: Used in water treatment, metal recovery, and electrochemical machining.
– Surface Finishing: Supports high-speed plating operations for automotive, aerospace, and electronics industries.

Customization and Tailored Engineering Services
GAOHUI offers full customization for your specific application, with a range of 1V-1000V and 1A-100,000A for AC-DC rectifiers. Available custom functions include:
– Digital Process Timer: Set precise plating duration with automatic shutdown.
– Multi-Stage Programmable Profile Control: Create up to 10-step current/voltage ramps for complex plating sequences.
– Ampere-Minute Integrator: Monitor total charge delivery for consistent coating thickness.
– Automatic Reverse Polarity: Switch output polarity for cleaning or stripping cycles.
– Soft-Start Ramp-Up: Gradual current increase to prevent thermal shock to parts.
– Local/Remote Control: Operate via push-button panel or HMI touch screen with password protection.
– Communication Interfaces: RS485 Modbus RTU, Ethernet, and 4-20mA analog control for integration with PLC systems.
– Pulse Functions: Adjustable pulse duty cycle from 1-100% and frequency from 1-3000Hz for improved deposit quality.
