Key Features & Engineering Highlights
– Built with advanced Germany technology cooling system for sustained heavy-duty DC power supply performance in high-purity silver bath applications, ensuring minimal thermal drift and maximum uptime at the industrial high frequency rectifier factory.
– Microsecond-level transient response delivers ultra-low ripple (90% efficiency at full load, providing a competitive heavy-duty DC power supply price while lowering operational costs for continuous silver electroplating lines.
– Digital control loop with 0.1% voltage and current regulation accuracy, enabling repeatable results for custom current voltage rectifier setups in precious metal finishing.
– Compact air-cooled design rated IP54 for harsh plating shop environments, eliminating water cooling maintenance and simplifying installation in space-constrained work cells.
Technical Specifications Table
| Model | GH-SP12-100A |
| Output Voltage Range | 0-12V DC (adjustable) |
| Output Current Range | 0-100A DC (adjustable) |
| Output Power | 1200W |
| Input Voltage | 3-Phase 380V/400V AC ±10%, 50/60Hz |
| Ripple & Noise | <1% RMS at full load |
| Regulation Accuracy | Voltage: ±0.1% / Current: ±0.1% |
| Cooling Method | Forced air cooling (Germany technology fan) |
| Protection Class | IP54 |
| Operating Temperature | -10°C to +50°C |
| Dimensions (W x D x H) | 420 x 480 x 220 mm |
| Weight | 28 kg |
Advanced Built-in Protection Systems
Overcurrent, overvoltage, overtemperature, short circuit, and phase loss protection are standard. The unit also includes soft-start ramp-up to prevent plating bath shock, automatic reverse polarity for periodic reversal cleaning cycles, and a digital process timer with alarm outputs for unattended operation. All protection thresholds are field-adjustable via the front panel or remote interface.
Target Industrial Applications
– Precision silver electroplating for electrical contact terminals, connectors, and switchgear components
– High-purity silver bath deposition for decorative and functional jewelry finishing
– Cyanide silver plating on base metals for corrosion resistance and solderability
– Gold and silver reverse electroplating for recovery and stripping processes
– Electrowinning and electroforming of precious metals in laboratory and production settings
– Hard anodizing and general DC electroplating where low ripple is critical
Customization and Tailored Engineering Services
As a dedicated IGBT rectifier manufacturer, GAOHUI offers full customization from 1V to 1000V and 1A to 100,000A DC output, with AC input only. We engineer custom functional modules to match your exact process:
– Digital Process Timer with programmable dwell and hold stages
– Multi-Stage Programmable Profile Control for ramped current/voltage sequences
– Ampere-Minute Integrator for precise thickness control
– Automatic Reverse Polarity for periodic pulse cleaning
– Soft-Start Ramp-Up to avoid thermal shock to bath chemicals
– Local/Remote Control via push-button or 7-inch HMI Touch Screen
– Communication Interfaces: RS485 Modbus RTU, Ethernet, 4-20mA analog
– Pulse Functions with adjustable duty cycle 1-100% and frequency 1-3000Hz
All units are factory-tested with full load burn-in and include a 24-month warranty.
