Key Features & Engineering Highlights
– Advanced IGBT technology with Germany engineered cooling system ensures stable 15V 1500A output for continuous anodizing operations, reducing downtime and maintenance costs for industrial high frequency rectifier factory applications.
– Heavy-duty DC power supply price optimized for B2B buyers seeking reliable custom current voltage rectifier solutions, featuring low ripple (<3%) for consistent oxide layer formation on architectural profile finishing.
– Digital control with multi-stage programmable profile enables precise voltage and current ramping, critical for sulfuric acid anodizing processes requiring tight tolerances and repeatability.
– Robust design with fully sealed power modules and corrosion-resistant enclosures, ideal for harsh plating shop environments where chemical exposure is common.
– Factory-direct from GAOHUI, a trusted IGBT rectifier manufacturer, offering competitive pricing without compromising on performance or longevity.
Technical Specifications Table
| Input Voltage | Three-phase AC 415V ±10%, 50Hz |
| Output Voltage | 0-15V DC (continuously adjustable) |
| Output Current | 0-1500A (continuously adjustable) |
| Output Mode | Constant Voltage / Constant Current with automatic crossover |
| Ripple | <3% at rated load |
| Efficiency | >90% at full load |
| Cooling System | German designed forced air cooling with intelligent fan control |
| Protection Class | IP54 (operator panel), IP20 (power section) |
| Operating Temperature | 0-45°C |
| Weight | Approximately 120 kg |
Advanced Built-in Protection Systems
– Overvoltage protection (OVP) automatically shuts down output if voltage exceeds preset limit, safeguarding sensitive anodizing baths.
– Overcurrent protection (OCP) with fast-acting IGBT gate drive cutoff prevents damage during load faults or short circuits.
– Overtemperature protection (OTP) with thermal sensors on heatsinks and transformer core, triggering alarm and shutdown if internal temperature exceeds 85°C.
– Phase loss and input under-voltage detection ensures stable operation even with fluctuating mains supply, typical in industrial environments.
– Soft-start ramp-up prevents current inrush and mechanical stress on rectifier components, extending service life.
Target Industrial Applications
– Aluminum anodizing line for architectural profiles, automotive trim, and consumer electronics enclosures requiring uniform oxide layers.
– Hard anodizing of aluminum alloys for aerospace components, defense parts, and high-wear industrial tools where coating thickness exceeds 25 microns.
– Chromic acid anodizing for corrosion-resistant coatings on aircraft structural parts and hydraulic systems.
– Sulfuric acid anodizing for decorative and protective finishes on extruded profiles, sheet metal, and castings.
– Electropolishing of stainless steel and titanium for medical implants, food processing equipment, and architectural panels.
– Plating rectifier for zinc, chrome, and nickel electrodeposition in job shops and captive lines.
Customization and Tailored Engineering Services
GAOHUI offers full customization from 1V to 1000V and 1A to 100,000A, AC-DC only, to match exact process requirements. Optional functional modules include Digital Process Timer for batch cycle control, Multi-Stage Programmable Profile Control with up to 16 steps for complex anodizing sequences, Ampere-Minute Integrator for precise coating thickness measurement, Automatic Reverse Polarity for periodic pulse plating, and Soft-Start Ramp-Up to avoid thermal shock. Control interface options include Local/Remote via Push-Button or HMI Touch Screen, RS485 Modbus RTU for PLC integration, Ethernet for plant-wide monitoring, 4-20mA analog interface for external controllers, and Pulse Functions with 1-100% duty cycle and 1-3000Hz frequency adjustable for advanced surface finishing. All units are built to order with lead times from 4 to 8 weeks depending on complexity.
