The 14V 2200A Barrel Plating Rectifier supplies 30.8 kW of adjustable DC power for bulk plating of small components in rotating barrels.
In barrel plating lines, the 14V 2200A Barrel Plating Rectifier provides an adjustable DC operating window for rotating loads, helping operators maintain current delivery as contact conditions and batch loading change through the cycle.
Power for a moving work load
In barrel plating, parts continually move and electrical contact changes through danglers or contact buttons. Stable regulation helps the line maintain the selected average current while the load tumbles. Deposit consistency also depends on barrel loading, rotation speed, contact condition, bath chemistry and anode arrangement.
Rated output
| DC output | 14V, 2200A |
|---|---|
| Rated power | 30.8 kW |
| Modes | Constant current and constant voltage |
| Cooling | Air or water cooling |
| Options | Timer, ramp, ampere-hour control, PLC and RS485 |
| Custom range | 1–1000V and 1–100,000A |
Sizing for production barrels
Current is based on the effective surface area of the maximum batch and its process current density. Voltage must include losses through the bath, barrel contacts, cables and busbars. Barrel size, part type and load weight help refine the rating.
Cycle controls
Timed programs, gradual current rise, accumulated ampere-hours and remote operation can follow the barrel line sequence. Run and alarm signals can connect to an automatic hoist controller.
Compare barrel plating rectifiers, browse industrial rectifiers, or send your barrel load details.
